  • Features / Environments
  • Specifications
  • Accessories
Features
  • Highly efficient solids handling
  • Easy tow
  • Silenced diesel engine
  • Fully electric start
  • Fully portable
  • Cost effective pumping
  • Hard wearing
  • No suction lift restrictions
Environments
  • Clean and dirty water
  • Slurry
  • Sewage
  • Waste water
  • Sludge
  • Ground water control
Weight
H100 - Pump end: 51 kg, H150 - Pump end: 105 kg, Powerpack: 995 kg
Fuel Tank Capacity
145 litres
Dimension
H100 - Pump end: 465 x 350 x 745 mm, H150 - Pump end: 650 x 500 x 970, Powerpack: 1900 x 1100 x 1720 (L x W x H)
Fuel Consumption
9 litres/hour
Noise level
@ 7m = 75 dBA
Pipe Connections
H100: 4" Bauer / H150: 6" Bauer
Performance
H100 - Max head: 40.0 m, Max flow: 62 l/s, Max solid: 38 mm, H150 - Max head: 22.0 m, Max flow: 95 l/s, Max solid: 65 mm
Engine(Type / Power / Speed)
HA394 28kW, 1800RPM
  • 3 LINE SET x 20M
  • DRIP TRAY 2440MM X 1525MM
  • DRIP TRAY 2058MM X 1525MM
  • RETAIL GAS OIL
  • BUNDED FUEL TANK 2000 LITRE
  • BUNDED FUEL TANK 2800 LITRE
  • BUNDED FUEL TANK 3000 LITRE
  • 5M HP FUEL LINE
