SUPER WISPASET 100 super silenced pump

The Super Wispaset 100 pump will deliver a flow rate of 160m³ per hour and is possibly the quietest pump on the market with a maximum noise level of 58dBA @ 7m. The Wispaset 100's most innovative feature is its optional Telemetry, which allows remote monitoring, removing the need for unnecessary and costly visits by engineers.

00971 800 79537 Get A Quote

Please enter your details. Items with a * are required.

SUPER WISPASET 100 super silenced pump Anlge View Click image to Zoom

Features

  • Reduced noise levels 58 dBA @ 7m
  • Oil pressure shut down
  • Optional Telemetry
  • Lifting eye security
  • Low cost operation
  • Oil mist filter
  • Optional Auto stop/start
  • 24 hour running
  • Optional high level bund alarm
  • Stackable Option
  • Optional low fuel warning
  • Skid and fast tow units
  • Temperature shut down
  • Engine options

Environments

  • Clean and dirty water
  • Emergency sewer repairs
  • Sludge
  • Utilities
  • Slurry
  • Quarries
  • Over pumping
  • Civil engineering
  • Site dewatering
  • Waste water

Accessories

  • 4" SPLIT INTAKE
  • 4" X 3M W/A BAUER HOSE
  • 4" 20FT W/A SUCTION HOSE BAUER
  • 4" 20FT POLYTUBE
  • 4" X 6M HELIFLEX PVC BAUER
  • 4" LAYFLAT HOSE PER METRE
  • 4" BLUE LAYFLAT X 25M CW BAUERS
  • 4" X 6MTR STEEL BAUER PIPE
  • 4" 45* BAUER BEND
  • 4" 90* BEND
  • 4" GATEVALVE
  • 4" NON RETURN VALVE
  • SETTLEMENT TANK
  • SYKES SILT AWAY
  • ROAD RAMP C/W 6" PN16 FLANGES
  • ROAD RAMP WIDE C/W 6" PN16 FLANGES
  • ROAD CROSSING C/W 8" PN16 FLANGES
  • BUNDED FUEL TANK 2000 LITRE
  • BUNDED FUEL TANK 2800 LITRE
  • BUNDED FUEL TANK 3000 LITRE
  • 5M HP FUEL LINE
  • RETAIL GAS OIL

Specifications

Weight
1685 kg with fuel / 1500 kg without fuel
Dimension
(LxWxH)mm: 2137x1250x1535
Control
Optional Auto stop start/ Optional telematery/ Optional shutdowns
Noise level
Typical noise level at 7m = 58 - 65 dBA
Performance
Max head: 31 m / Max flow: 45 l/s / Max solid: 44 mm
Fuel Tank Capacity
158 litres. Max 24h running
Fuel Consumption
Typical fuel consumption on full load @ 1800 rpm: 5 litres/hour
Chassis
High speed trailer / Skid mounted / Fork Lift slots / Fully Bunded
Canopy
Metalised soundabsorbing Canopy / Zintec coating on all surfaces
Pump Materials
Main pump: SG grade iron
Pipe Connections
Suction: 4" Table D, Discharge: 4" Table D, Bauer couplings option
Engine(Type / Power / Speed)
Kubota V2203 / 21 kW / 1800 rpm, Deutz D2009L03 / 20 kW / 1800 rpm
Prime System
Flood Lubricated Rotary Vacuum Pump/ Nominal Displacement 25CFM/ Non Return Valve
Shaft Seal
Sykes patented Vacuum pressure seal, Single ring of packing, Spring loaded, No adjustments necessary, Easy repacking, Chrome oxide coating on wear ring, Optional mechanical seal
Health and Safety
Gloves / Boots/safety footwear / Protective clothing / Noise power level Lwa: 90 dB
